| Ports & interfaces |
|---|
| Number of computers controlled | 8 |
| Keyboard port type | USB |
| Number of microphone inputs | 8 |
| Mouse port type | USB |
| Video port type | HDMI |
| HDMI version | 2.0 |
| Headphone outputs | 1 |
| HDMI ports quantity | 8 |
| DC-in jack | Yes |
| Console USB ports quantity | 4 |
| Console ports | 3.5mm headphone, HDMI, USB A |
| USB 2.0 Type-B ports quantity | 8 |
| Performance |
|---|
| Data transfer rate (max) | 0.48 Gbit/s |
| HD type | 4K Ultra HD |
| Maximum resolution | 3840 x 2160 pixels |
| Scan interval | 10,20,30,40,50,60,70,80,90,100 s |
| Daisy chain | No |
| Audio channels | 2.0 |
| Design |
|---|
| Product colour | Black |
| Rack mounting | Yes |
| Push button | Yes |
| Mean time between failures (MTBF) | 73905 h |
| LED indicators | Yes |
| Hot keys | Yes |
| Rack capacity | 1U |
| Housing material | Zinc |
| Display |
|---|
| Built-in display | No |
| On Screen Display (OSD) | No |
| Power |
|---|
| Output voltage | 12 V |
| Input current | 1 A |
| Power source | DC |
| Output current | 3 A |
| Power consumption (typical) | 36 W |
| Power plug type | Type M |
| Compatible power plug types | AU, EU, UK, US |
| Input voltage | 100 - 240 V |
| Video |
|---|
| HD type | 4K Ultra HD |
| Maximum resolution | 3840 x 2160 pixels |
| Sustainability |
|---|
| Compliance certificates | Federal Communications Commission (FCC), Trade Agreements Act (TAA) |
| Operational conditions |
|---|
| Operating temperature (T-T) | 0 - 40 °C |
| Storage temperature (T-T) | -20 - 60 °C |
| Operating relative humidity (H-H) | 0 - 90% |
| Weight & dimensions |
|---|
| Width | 6.46" (164 mm) |
| Depth | 11.8" (300 mm) |
| Height | 1.73" (44 mm) |
| Weight | 3.31 lbs (1.5 kg) |
| Package width | 17.1" (435 mm) |
| Package depth | 11.3" (288 mm) |
| Package height | 2.76" (70 mm) |
| Package weight | 5.07 lbs (2.3 kg) |
| Packaging data |
|---|
| Package width | 17.1" (435 mm) |
| Package depth | 11.3" (288 mm) |
| Package height | 2.76" (70 mm) |
| Package weight | 5.07 lbs (2.3 kg) |
| Packaging content |
|---|
| Rack mount kit | Yes |
| Quick installation guide | Yes |
| Other features |
|---|
| IP control | No |
| Push button | Yes |
| Hot keys | Yes |
| Technical details |
|---|
| Compliance certificates | Federal Communications Commission (FCC), Trade Agreements Act (TAA) |
| Logistics data |
|---|
| Master (outer) case width | 23" (585 mm) |
| Master (outer) case length | 21.5" (545 mm) |
| Master (outer) case height | 10.6" (270 mm) |
| Products per master (outer) case | 5 pc(s) |
