| Ports & interfaces |
|---|
| Internal | No |
| Connectivity technology | Wired |
| Host interface | USB Type-C |
| Interface | Ethernet |
| Ethernet LAN (RJ-45) ports | 1 |
| USB version | 3.2 Gen 1 (3.1 Gen 1) |
| USB connector form factor | Straight |
| Bandwidth |
|---|
| Maximum data transfer rate | 5000 Mbit/s |
| Full duplex | Yes |
| Network |
|---|
| Chipset | Realtek RTL8156BG |
| Maximum data transfer rate | 5000 Mbit/s |
| Ethernet LAN | Yes |
| Ethernet interface type | 2.5 Gigabit Ethernet, Fast Ethernet, Gigabit Ethernet |
| Jumbo frames | 16000 |
| Ethernet LAN data rates | 10,100,1000,2500 Mbit/s |
| Cabling technology | NBase-T |
| Networking standards | IEEE 802.1Q, IEEE 802.3ab, IEEE 802.3bz, IEEE 802.3i, IEEE 802.3u, IEEE 802.3x |
| Wake-on-LAN ready | Yes |
| Auto MDIX IEEE | Yes |
| Jumbo frames support | Yes |
| Full duplex | Yes |
| VLAN support | Yes |
| Design |
|---|
| Internal | No |
| Product colour | Gray |
| Chipset | Realtek RTL8156BG |
| Mean time between failures (MTBF) | 1912948 h |
| LED indicators | Yes |
| Component for | PC/Laptop |
| Power |
|---|
| Output voltage | 5 V |
| USB powered | Yes |
| System requirements |
|---|
| Windows operating systems supported | Windows 11 Enterprise x64, Windows 7 Professional x64, Windows 8.1 Pro, Windows 10, Windows 11 Home, Windows 7 Starter, Windows 8.1 Pro x64, Windows 10 Education, Windows 11 Pro, Windows 7 Starter x64, Windows 8.1 x64, Windows 10 Education x64, Windows 11 x64, Windows 7 Ultimate, Windows 10 Enterprise, Windows 7 Ultimate x64, Windows 10 Enterprise x64, Windows 7 x64, Windows 10 Home, Windows 8, Windows 10 Home x64, Windows 7, Windows 8 Enterprise, Windows 10 IOT Core, Windows 7 Enterprise, Windows 8 Enterprise x64, Windows 10 IoT Enterprise, Windows 7 Enterprise x64, Windows 8 Pro, Windows 10 Pro, Windows 7 Home Basic, Windows 8 Pro x64, Windows 10 Pro x64, Windows 7 Home Basic x64, Windows 8 x64, Windows 10 x64, Windows 7 Home Premium, Windows 8.1, Windows 11, Windows 7 Home Premium x64, Windows 8.1 Enterprise, Windows 11 Enterprise, Windows 7 Professional, Windows 8.1 Enterprise x64 |
| Mac operating systems supported | Mac OS X 10.14 Mojave, Mac OS X 10.15 Catalina, Mac OS X 10.15.3 Catalina, Mac OS X 11.0 Big Sur, Mac OS X 10.11 El Capitan, Mac OS X 12.0 Monterey, Mac OS X 10.12 Sierra, Mac OS X 13.0 Ventura, Mac OS X 10.13 High Sierra, Mac OS X 14.0 Sonoma |
| Linux operating systems supported | Yes |
| Server operating systems supported | Windows Server 2012 R2, Windows Server 2008 R2, Windows Server 2016, Windows Server 2022 |
| Weight & dimensions |
|---|
| Width | 0.866" (22 mm) |
| Depth | 5.98" (152 mm) |
| Height | 0.591" (15 mm) |
| Weight | 0.635 oz (18 g) |
| Package width | 8.66" (220 mm) |
| Package depth | 5.04" (128 mm) |
| Package height | 0.63" (16 mm) |
| Package weight | 0.847 oz (24 g) |
| Packaging data |
|---|
| Package width | 8.66" (220 mm) |
| Package depth | 5.04" (128 mm) |
| Package height | 0.63" (16 mm) |
| Package weight | 0.847 oz (24 g) |
| Performance |
|---|
| Wake-on-LAN ready | Yes |
| Auto MDIX IEEE | Yes |
| Mean time between failures (MTBF) | 1912948 h |
| Cable length | 5.98" (0.152 m) |
| Windows operating systems supported | Windows 11 Enterprise x64, Windows 7 Professional x64, Windows 8.1 Pro, Windows 10, Windows 11 Home, Windows 7 Starter, Windows 8.1 Pro x64, Windows 10 Education, Windows 11 Pro, Windows 7 Starter x64, Windows 8.1 x64, Windows 10 Education x64, Windows 11 x64, Windows 7 Ultimate, Windows 10 Enterprise, Windows 7 Ultimate x64, Windows 10 Enterprise x64, Windows 7 x64, Windows 10 Home, Windows 8, Windows 10 Home x64, Windows 7, Windows 8 Enterprise, Windows 10 IOT Core, Windows 7 Enterprise, Windows 8 Enterprise x64, Windows 10 IoT Enterprise, Windows 7 Enterprise x64, Windows 8 Pro, Windows 10 Pro, Windows 7 Home Basic, Windows 8 Pro x64, Windows 10 Pro x64, Windows 7 Home Basic x64, Windows 8 x64, Windows 10 x64, Windows 7 Home Premium, Windows 8.1, Windows 11, Windows 7 Home Premium x64, Windows 8.1 Enterprise, Windows 11 Enterprise, Windows 7 Professional, Windows 8.1 Enterprise x64 |
| Mac operating systems supported | Mac OS X 10.14 Mojave, Mac OS X 10.15 Catalina, Mac OS X 10.15.3 Catalina, Mac OS X 11.0 Big Sur, Mac OS X 10.11 El Capitan, Mac OS X 12.0 Monterey, Mac OS X 10.12 Sierra, Mac OS X 13.0 Ventura, Mac OS X 10.13 High Sierra, Mac OS X 14.0 Sonoma |
| Linux operating systems supported | Yes |
| Server operating systems supported | Windows Server 2012 R2, Windows Server 2008 R2, Windows Server 2016, Windows Server 2022 |
| Other features |
|---|
| Chipset | Realtek RTL8156BG |
| Jumbo frames | 16000 |
| Cable length | 5.98" (0.152 m) |
| Technical details |
|---|
| Compliance certificates | CE, RoHS |
| Logistics data |
|---|
| Master (outer) case width | 19.7" (500 mm) |
| Master (outer) case length | 12.6" (320 mm) |
| Master (outer) case height | 8.27" (210 mm) |
| Products per master (outer) case | 250 pc(s) |
