| Projector |
|---|
| Projector brightness | 20000 ANSI lumens |
| Projection technology | 3LCD |
| Projector native resolution | WUXGA (1920x1200) |
| Supported aspect ratios | 4:3, 16:10, 16:9 |
| Contrast ratio (typical) | 2500000:1 |
| Number of colours | 1.07 billion colors |
| White light output | 20000 ANSI lumens |
| Uniformity | 85% |
| Matrix type | 3-panel (p-Si TFT active) |
| Keystone correction, vertical | ±45° |
| Keystone correction, horizontal | ±30° |
| Colour light output | 20000 ANSI lumens |
| Light source |
|---|
| Light source type | Laser |
| Service life of light source | 20000 h |
| Lens system |
|---|
| Focus | Auto |
| Number of optional lenses supported | 9 |
| Focal length range | 14.8 – 17.7 |
| Aperture range (F-F) | 2 - 2.1 |
| Horizontal lens shift range | -18 - 18% |
| Vertical lens shift range | -60 - 60% |
| Throw ratio | 1.57 – 2.56 |
| Optical zoom | 1.6x |
| Interchangeable lens | Yes |
| Video |
|---|
| Supported video modes | 480i, 480p, 576i, 576p, 720p, 1080i, 1080p, 2160i, 2160p |
| Supported graphics resolutions | 640 x 480 (VGA), 720 x 576, 1920 x 1080 (HD 1080), 1920 x 1200 (WUXGA), 3840 x 2160, 4096 x 2160 |
| Ports & interfaces |
|---|
| HDBaseT port | Yes |
| VGA (D-Sub) ports quantity | 1 |
| HDMI ports quantity | 1 |
| HDMI connector type | Full-size |
| Serial interface type | RS-232C |
| DVI port | Yes |
| AC (power) in | Yes |
| Service port type | USB Type-B |
| USB 2.0 Type-A ports quantity | 2 |
| Network |
|---|
| Ethernet LAN | Yes |
| Ethernet LAN (RJ-45) ports | 1 |
| Features |
|---|
| HDCP | Yes |
| Password protection | Yes |
| Noise level | 45 dB |
| Noise level (economic mode) | 37 dB |
| High Dynamic Range (HDR) supported | Yes |
| Projection modes | Ceiling, Front, Rear |
| HDCP version | 2.3 |
| Test patterns | Yes |
| Multimedia |
|---|
| Timeshift | Yes |
| Design |
|---|
| Market positioning | Presentation |
| Product colour | Black |
| Product type | Large venue projector |
| Cable lock slot type | Kensington |
| Cable lock slot | Yes |
| Power |
|---|
| Power source | AC |
| Power consumption (typical) | 1301 W |
| Power consumption (standby) | 2 W |
| AC input voltage | 220 - 240 V |
| AC input frequency | 50 - 60 Hz |
| Power consumption (economy mode) | 899 W |
| Operational conditions |
|---|
| Operating temperature (T-T) | 0 - 50 °C |
| Weight & dimensions |
|---|
| Width | 23.1" (587 mm) |
| Depth | 19.4" (493 mm) |
| Height | 8.58" (218 mm) |
| Weight | 53.8 lbs (24.4 kg) |
| Packaging content |
|---|
| Remote control included | Yes |
| Packaging content | EB-PU2220B projector, power cable, remote control with two batteries, cable cover, user guide and warranty sheet |
| Warranty card | Yes |
| Manual | Yes |
| Cables included | AC |
| Batteries included | Yes |
| Technical details |
|---|
| Packaging content | EB-PU2220B projector, power cable, remote control with two batteries, cable cover, user guide and warranty sheet |
| Compliance certificates | RoHS |
