| Design |
|---|
| PDU types | Monitored |
| Mounting | Horizontal/Vertical |
| Type | Single-phase |
| Display | LCD |
| Product colour | Black |
| Certification | CE, FCC A, UL60950, EN 55032 A |
| Rack capacity | 1U |
| Housing material | Steel |
| Ports & interfaces |
|---|
| Power plug | C20 coupler |
| AC outlets quantity | 8 AC outlet(s) |
| AC outlet types | C13 coupler |
| USB ports quantity | 1 |
| Serial ports quantity | 1 |
| Ethernet LAN (RJ-45) ports | 1 |
| Features |
|---|
| LED indicators | Link, Status |
| Cable length | 120.1" (3.05 m) |
| Certification | CE, FCC A, UL60950, EN 55032 A |
| Daisy chain | Yes |
| Management features |
|---|
| Supported network protocols | IPv4/v6, SNMPv1/v3, HTTP/HTTPs, TCP/IP, UDP, DHCP, NTP, DNS, SMTP, SSH, SSL, TLS, Telnet, FTP, Syslog |
| Firmware upgradeable via | USB |
| Firmware upgradeable | Yes |
| Monitoring | Current, Power, Voltage |
| Ergonomics |
|---|
| Display | LCD |
| LED indicators | Link, Status |
| Cable length | 120.1" (3.05 m) |
| Power |
|---|
| Nominal input voltage | 100 - 240 V |
| Maximum current | 16 A |
| AC input frequency | 50 - 60 Hz |
| Weight & dimensions |
|---|
| Dimensions (WxDxH) | 17 x 4.41 x 1.73" (433 x 112 x 44 mm) |
| Weight | 4.19 lbs (1.9 kg) |
| Width | 17" (433 mm) |
| Depth | 4.41" (112 mm) |
| Height | 1.73" (44 mm) |
| Package width | 19.7" (500 mm) |
| Package depth | 9.84" (250 mm) |
| Package height | 2.56" (65 mm) |
| Package weight | 8.16 lbs (3.7 kg) |
| Packaging data |
|---|
| Package width | 19.7" (500 mm) |
| Package depth | 9.84" (250 mm) |
| Package height | 2.56" (65 mm) |
| Package weight | 8.16 lbs (3.7 kg) |
| Operational conditions |
|---|
| Operating temperature (T-T) | 0 - 55 °C |
| Storage temperature (T-T) | -15 - 60 °C |
| Storage relative humidity (H-H) | 0 - 95% |
| Operating relative humidity (H-H) | 0 - 95% |
| Operating altitude | 0 - 137795.3" (0 - 3500 m) |
| Non-operating altitude | 0 - 590551.2" (0 - 15000 m) |
| Operating temperature (T-T) | 32 - 131 °F |
| Technical details |
|---|
| Compliance certificates | RoHS |
