Display |
---|
Display diagonal | 24" |
Display resolution | 1920 x 1080 pixels |
Display brightness | 1500 cd/m² |
HD type | Full HD |
Response time | 14 ms |
Contrast ratio (typical) | 1000:1 |
Viewing angle, horizontal | 178° |
Viewing angle, vertical | 178° |
Pixel pitch | 0.0108 x 0.0108" (0.275 x 0.275 mm) |
Touchscreen | No |
Panel type | IPS |
Haze rate | 25% |
RGB colour space | NTSC |
Ports & interfaces |
---|
Ethernet LAN | Yes |
HDMI ports quantity | 1 |
HDMI version | 2.0a |
USB port | Yes |
Audio (L/R) out | 1 |
Ethernet LAN (RJ-45) ports | 1 |
RS-232 interface | Yes |
Wi-Fi | Yes |
USB ports quantity | 2 |
HDMI input ports quantity | 1 |
Design |
---|
Product design | Digital signage flat panel |
Product colour | Black |
VESA mounting | Yes |
Panel mounting interface | 100 x 100 mm |
Placement supported | Indoor/outdoor |
Orientation | Horizontal |
Bezel width (top) | 0.862" (2.19 cm) |
Bezel width (side) | 0.862" (2.19 cm) |
Bezel width (bottom) | 0.862" (2.19 cm) |
Performance |
---|
Purpose | Commercial |
Operating hours (hours/days) | 24/7 |
HDCP | Yes |
HDCP version | 2.2 |
Wi-Fi | Yes |
Power |
---|
Power consumption (typical) | 90 W |
Power consumption (standby) | 0.5 W |
AC input voltage | 100 - 240 V |
AC input frequency | 50 - 60 Hz |
Computer system |
---|
Operating system installed | Tizen 6.5 |
Weight & dimensions |
---|
Display width | 22.6" (573 mm) |
Display depth | 2.35" (59.8 mm) |
Display height | 13.5" (342.4 mm) |
Display weight | 18.5 lbs (8.4 kg) |
Packaging data |
---|
Package width | 28.7" (730 mm) |
Package depth | 5.51" (140 mm) |
Package height | 17.2" (438 mm) |
Package weight | 22 lbs (10 kg) |
Operational conditions |
---|
Operating temperature (T-T) | -30 - 50 °C |
Operating relative humidity (H-H) | 10 - 80% |
Thin Client |
---|
Operating system installed | Tizen 6.5 |
Technical details |
---|
Panel type | IPS |
Other features |
---|
Wi-Fi | Yes |
Panel type | IPS |
Bezel width (top) | 0.862" (2.19 cm) |
Bezel width (side) | 0.862" (2.19 cm) |
Bezel width (bottom) | 0.862" (2.19 cm) |
