Projector |
---|
Projector brightness | 5000 ANSI lumens |
Projection technology | DLP |
Projector native resolution | 1080p (1920x1080) |
Screen size compatibility | 30 - 300" |
Native aspect ratio | 16:9 |
Supported aspect ratios | 4:3, 16:10, 16:9 |
Projection distance | 29.9 - 393.7" (0.76 - 10 m) |
Contrast ratio (dynamic) | 50000:1 |
Number of colours | 1.073 billion colors |
Vertical scan range | 23 - 120 Hz |
Horizontal scan range | 15 - 102 kHz |
Matrix type | DMD |
Matrix size | 0.65" |
Keystone correction, vertical | -40 - 40° |
Light source |
---|
Lamps quantity | 1 lamp(s) |
Lamp power | 370 W |
Light source type | Lamp |
Service life of light source | 2000 h |
Service life of light source (economic mode) | 2500 h |
Lens system |
---|
Zoom ratio | 1.3:1 |
Zoom capability | Yes |
Focus | Manual |
Throw ratio | 1.15 - 1.5 |
Zoom type | Manual |
Video |
---|
Analog signal format system | NTSC, PAL, PAL 60, SECAM |
Full HD | Yes |
3D | No |
Supported video modes | 480i, 480p, 576i, 576p, 720p, 1080i, 1080p |
Supported graphics resolutions | 640 x 480 (VGA), 720 x 480, 720 x 576, 800 x 600 (SVGA), 1024 x 768 (XGA), 1152 x 864 (XGA+), 1152 x 870, 1280 x 720 (HD 720), 1280 x 768 (WXGA), 1280 x 800 (WXGA), 1280 x 960, 1360 x 768 (WXGA), 1400 x 1050 (SXGA+), 1440 x 900 (WXGA+), 1600 x 1200 (UXGA), 1680 x 1050 (WSXGA+), 1920 x 1080 (HD 1080), 1920 x 1200 (WUXGA) |
Ports & interfaces |
---|
Remote (IR) output | 1 |
12V trigger | Yes |
USB 2.0 Type-B ports quantity | 1 |
VGA (D-Sub) ports quantity | 3 |
HDMI ports quantity | 2 |
HDMI connector type | Full-size |
USB 2.0 ports quantity | 1 |
Composite video in | 1 |
Audio (L/R) in | 1 |
S-Video inputs quantity | 1 |
Serial interface type | RS-232 |
PC Audio out | Yes |
PC Audio in | Yes |
DVI port | No |
AC (power) in | Yes |
Network |
---|
Ethernet LAN | Yes |
Wi-Fi | No |
Ethernet LAN (RJ-45) ports | 1 |
Storage |
---|
Card reader integrated | No |
Features |
---|
On Screen Display (OSD) | Yes |
Certification | FCC, ROHS, cTUVus |
Multimedia |
---|
Built-in speaker(s) | Yes |
Number of built-in speakers | 2 |
RMS rated power | 20 W |
Design |
---|
Product colour | White |
Product type | Standard throw projector |
Cable lock slot type | Kensington |
Cable lock slot | Yes |
Placement | Desktop |
Display |
---|
Built-in display | No |
Power |
---|
Power source | AC |
Power consumption (typical) | 468.85 W |
Power consumption (standby) | 0.5 W |
Power consumption (max) | 574 W |
AC input voltage | 100 - 240 V |
AC input frequency | 50 - 60 Hz |
Software |
---|
Mac compatibility | Yes |
Operational conditions |
---|
Operating temperature (T-T) | 0 - 40 °C |
Operating relative humidity (H-H) | 0 - 90% |
Operating altitude | 0 - 118110.2" (0 - 3000 m) |
Weight & dimensions |
---|
Width | 18.5" (470 mm) |
Depth | 5.51" (140 mm) |
Height | 12.4" (316 mm) |
Weight | 13.7 lbs (6.2 kg) |
Package width | 22.7" (577 mm) |
Package depth | 10.2" (260 mm) |
Package height | 21.1" (537 mm) |
Package weight | 18.7 lbs (8.5 kg) |
Packaging content |
---|
Remote control included | Yes |
Quick start guide | Yes |
Cables included | AC, VGA |
Batteries included | Yes |
Other features |
---|
RS-232 ports | 1 |
