Processor |
---|
Processor frequency | 3.8 GHz |
Processor family | Intel Xeon W |
Processor manufacturer | Intel |
Processor model | W-2235 |
Processor cores | 6 |
Processor boost frequency | 4.6 GHz |
Processor threads | 12 |
Memory |
---|
Internal memory | 32 GB |
Internal memory type | DDR4-SDRAM |
Maximum internal memory | 512 GB |
Memory layout (slots x size) | 2 x 16 GB |
Memory slots | 8x DIMM |
Memory clock speed | 2933 MHz |
Storage |
---|
Total storage capacity | 1 TB |
Optical drive type | No |
Card reader integrated | Yes |
Storage media | SSD |
Number of SSDs installed | 1 |
SSD capacity | 1 TB |
SSD interface | PCI Express |
Compatible memory cards | SD |
SSD form factor | M.2 |
Total SSDs capacity | 1 TB |
Graphics |
---|
Discrete graphics card | Yes |
Discrete graphics card model | NVIDIA Quadro RTX 4000 |
On-board graphics card model | Not available |
Discrete graphics card memory | 8 GB |
On-board graphics card | No |
Optical drive |
---|
Optical drive type | No |
Network |
---|
Ethernet LAN | Yes |
Ethernet LAN data rates | 10,100,1000 Mbit/s |
Cabling technology | 10/100/1000Base-T(X) |
Wi-Fi | No |
Ports & interfaces |
---|
USB 2.0 ports quantity | 2 |
DVI port | No |
PS/2 ports quantity | 2 |
Ethernet LAN (RJ-45) ports | 1 |
Line-in | Yes |
Line-out | Yes |
Microphone in | Yes |
Headphone outputs | 1 |
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 8 |
Combo headphone/mic port | Yes |
Design |
---|
Product colour | Black |
Chassis type | Tower |
Placement supported | Vertical |
Cable lock slot | Yes |
Cable lock slot type | Kensington |
Volume | 33 L |
Viewing window | No |
Performance |
---|
Product type | Workstation |
Motherboard chipset | Intel® C422 |
Audio system | High Definition Audio |
Password protection | Yes |
Password protection type | Power on, Supervisor |
Audio chip | Realtek ALC662 |
Trusted Platform Module (TPM) | Yes |
Embedded options available | No |
Software |
---|
Operating system installed | Windows 10 Pro for Workstations |
Operating system architecture | 64-bit |
Processor special features |
---|
Intel VT-x with Extended Page Tables (EPT) | Yes |
Intel TSX-NI | Yes |
Intel Trusted Execution Technology | Yes |
Idle States | Yes |
Execute Disable Bit | Yes |
Intel Flex Memory Access | No |
Intel Software Guard Extensions (Intel SGX) | No |
Intel Demand Based Switching | Yes |
Intel Virtualization Technology for Directed I/O (VT-d) | Yes |
CPU configuration (max) | 1 |
Intel Virtualization Technology (VT-x) | Yes |
Intel 64 | Yes |
Enhanced Intel SpeedStep Technology | Yes |
Embedded options available | No |
Power |
---|
Power supply | 1000 W |
Power supply input voltage | 100 - 240 V |
Operational conditions |
---|
Operating temperature (T-T) | 10 - 35 °C |
Operating relative humidity (H-H) | 20 - 80% |
Operating altitude | 0 - 120000" (0 - 3048 m) |
Non-operating altitude | 0 - 480000" (0 - 12192 m) |
Storage temperature (T-T) | -40 - 60 °C |
Storage relative humidity (H-H) | 10 - 90% |
Certificates |
---|
Compliance certificates | RoHS |
Sustainability |
---|
Sustainability certificates | ENERGY STAR, EPEAT Silver |
Weight & dimensions |
---|
Volume | 33 L |
Width | 6.5" (165 mm) |
Depth | 18.1" (460 mm) |
Height | 17.3" (440 mm) |
Weight | 52.9 lbs (24 kg) |
Packaging content |
---|
Display included | No |
Mouse included | Yes |
Keyboard included | Yes |
Technical details |
---|
Sustainability certificates | ENERGY STAR, EPEAT Silver |
Compliance certificates | RoHS |
Other features |
---|
Processor manufacturer | Intel |
Trusted Platform Module (TPM) | Yes |
On-board graphics card | No |
