D-Link DWL-8710AP D-Link DWL-8710AP wireless access point 1167 Mbit/s White Power over Ethernet (PoE)

Availability :
Limited Availability
Mfr. Part# :
DWL-8710AP
CAD 1,141.01
Quantity :

PRODUCT DETAILS:

The DWL-8710AP is an outdoor dual-band Wireless AC1200 Access Point designed specifically for deployment in business and campus environments. Highly manageable and capable of blazing speeds, the DWL-8710AP integrates seamlessly into an existing network infrastructure and can be easily scaled to meet future demands.Convenient InstallationThe DWL-8710AP can be installed on a wall or pole with the included mounting brackets. The DWL-8710AP is IP67-compliant and is designed to operate in harsh outdoor environments and temperatures ranging from -30 up to 60˚C. For easy installation, it has integrated 802.3at Power over Ethernet (PoE) support, allowing installation of this device in areas where power outlets are not readily available.Superior Wireless AC PerformanceThe DWL-8710AP delivers reliable, high-speed wireless performance using the latest 802.11ac standards. Band steering ensures 5GHz-enabled clients can achieve their maximum performance without being bottle-necked by legacy 2.4 GHz 802.11b/g/n clients. AC SmartBeam™ technology enables the DWL-8710AP to have even greater reach than ever before.Simultaneous Dual-Band WirelessDelivers reliable wireless performance with maximum wireless signal rates of up to 300 Mbps over the 2.4 GHz band, and 867 Mbps over the 5 GHz bandBroadcast on 32 SSIDs SimultaneouslySupports up to 32 SSIDs, 16 per radio, including Station IsolationCentrally Manage your Wireless NetworkWhen working in conjunction with a D-Link Unified Switch or Wireless Controller, the DWL-8710AP, like other D-Link Unified Access Points, may be centrally managed. This allows up to 1,024 D-Link Unified Access Points to be deployed and managed easily and efficiently. This managed wireless solution offers self-organising, self-optimising and self-healing network capabilities to increase the stability of the entire wireless network.

Performance
Maximum data transfer rate1167 Mbit/s
Ethernet LAN data rates1000 Mbit/s
2.4 GHzYes
5 GHzYes
Frequency band2.4 - 2.4835, 5.18 - 5.24, 5.28 - 5.32, 5.5 - 5.7, 5.745 - 5.825 GHz
Wireless isolationYes
Automatic channel selectionYes
Web-based managementYes
VLAN supportYes
Networking standardsIEEE 802.11a, IEEE 802.11ac, IEEE 802.11g, IEEE 802.11n, IEEE 802.1Q, IEEE 802.3at
Channels quantity165 channels
CertificationCE, EN 301 893 V1.7.1 (2012-06) (DFS/TPC), EN 300, 328 V1.8.1 (2012-06), FCC, IC, cUL, C-Tick, NCC, Wi-Fi, LVD, BSMI
Features
Maximum data transfer rate1167 Mbit/s
Ethernet LAN data rates1000 Mbit/s
2.4 GHzYes
5 GHzYes
Frequency band2.4 - 2.4835, 5.18 - 5.24, 5.28 - 5.32, 5.5 - 5.7, 5.745 - 5.825 GHz
Wireless isolationYes
Automatic channel selectionYes
VLAN supportYes
Networking standardsIEEE 802.11a, IEEE 802.11ac, IEEE 802.11g, IEEE 802.11n, IEEE 802.1Q, IEEE 802.3at
Channels quantity165 channels
Maximum data transfer rate (5 GHz)867 Mbit/s
Security
Security algorithmsAES, SNMP, SSH, SSID, TKIP, WPA, WPA2
Number of SSID supported32
MAC address filteringYes
Management features
Web-based managementYes
Ports & interfaces
Ethernet LAN (RJ-45) ports2
Power
Power consumption (max)16.5 W
Power over Ethernet (PoE)Yes
Design
InternalNo
PlacementPole, Wall
International Protection (IP) codeIP67
Housing materialMetal, Polycarbonate (PC)
Product colourWhite
CertificationCE, EN 301 893 V1.7.1 (2012-06) (DFS/TPC), EN 300, 328 V1.8.1 (2012-06), FCC, IC, cUL, C-Tick, NCC, Wi-Fi, LVD, BSMI
Antenna
Number of connectors4
Antennas quantity4
Antenna gain level (max)7 dBi
Antenna connector typeN-type
Technical details
Shipping (inner) case width12.1" (30.7 cm)
Shipping (inner) case net weight17.1 lbs (7.75 kg)
Shipping (inner) case length14.6" (37.2 cm)
Shipping (inner) case height12.4" (31.4 cm)
Products per shipping (inner) case2 pc(s)
Products per pallet (sea)60 pc(s)
Products per pallet (air)36 pc(s)
Pallet gross width47.2" (120 cm)
Pallet gross length43.3" (110 cm)
Pallet height (sea)67.1" (170.5 cm)
Pallet height (air)42.4" (107.7 cm)
Pallet gross weight (sea)594.6 lbs (269.7 kg)
Pallet gross weight (air)369.9 lbs (167.8 kg)
Master (outer) cases per pallet (sea)30 pc(s)
Master (outer) cases per pallet (air)18 pc(s)
Shipping (inner) case gross weight18.7 lbs (8.49 kg)
Harmonized System (HS) code85176990
Weight & dimensions
Width9.84" (250 mm)
Depth1.77" (45 mm)
Height8.66" (220 mm)
Weight4.52 lbs (2.05 kg)
Package width11.9" (301 mm)
Package depth14.5" (369 mm)
Package height5.79" (147 mm)
Package weight8.53 lbs (3.87 kg)
Packaging data
Package width11.9" (301 mm)
Package depth14.5" (369 mm)
Package height5.79" (147 mm)
Package weight8.53 lbs (3.87 kg)
Operational conditions
Operating relative humidity (H-H)10 - 90%
Operating temperature (T-T)-30 - 60 °C
Storage temperature (T-T)-30 - 70 °C
Logistics data
Harmonized System (HS) code85176990
