Performance |
---|
Type | IP security camera |
Connectivity technology | Wired |
Placement supported | Indoor |
Certification | CE, FCC 15 A, ICES-003 A, VCCI A, EN 55022 A, EN 55024, AS/NZS CISPR 22 |
Design |
---|
Form factor | Cube |
Product colour | Black |
Mounting type | Wall |
LED indicators | Activity |
Camera |
---|
Lens viewing angle, horizontal | 64° |
Lens viewing angle, vertical | 53° |
Video |
---|
Maximum resolution | 1280 x 1024 pixels |
Supported graphics resolutions | 640 x 480 (VGA), 1280 x 1024 (SXGA) |
Frame rate | 30 fps |
Audio |
---|
Audio system | 2-way |
Network |
---|
Bluetooth | No |
Ethernet LAN | Yes |
Wi-Fi | No |
Storage |
---|
Built-in HDD | No |
Ports & interfaces |
---|
USB port | Yes |
Microphone in | Yes |
Interface | RJ-45 |
Headphone outputs | 1 |
Connectivity technology | Wired |
Power |
---|
Power source type | DC |
Power over Ethernet (PoE) | No |
Power consumption (max) | 2 W |
DC output voltage | 5 |
Certificates |
---|
Certification | CE, FCC 15 A, ICES-003 A, VCCI A, EN 55022 A, EN 55024, AS/NZS CISPR 22 |
Operational conditions |
---|
Operating temperature (T-T) | 0 - 45 °C |
Storage temperature (T-T) | -15 - 65 °C |
Operating relative humidity (H-H) | 10 - 90% |
Storage relative humidity (H-H) | 10 - 90% |
Weight & dimensions |
---|
Width | 3.94" (100 mm) |
Depth | 3.07" (78 mm) |
Height | 4.02" (102 mm) |
Weight | 7.05 oz (200 g) |
Package width | 11.3" (286 mm) |
Package depth | 6.5" (165 mm) |
Package height | 10.2" (260 mm) |
Package weight | 3.09 lbs (1.4 kg) |
Packaging content |
---|
Number of cameras | 1 |
Technical details |
---|
Lens mount interface | CS mount |
Logistics data |
---|
Harmonized System (HS) code | 85258900 |
