| Power |
|---|
| Surge energy rating | 840 J |
| AC outlets quantity | 6 AC outlet(s) |
| AC outlet types | NEMA 5–15R |
| Nominal input voltage | 120 V |
| Peak current, normal mode | 10000 A |
| Peak current, common mode | 30000 A |
| Nominal current output | 15 A |
| AC input frequency | 50 - 60 Hz |
| Ports & interfaces |
|---|
| Power plug | NEMA 5–15P |
| Features |
|---|
| EMI/RFI noise filtering | Yes |
| EMI/RFI noise filtering | 20 dB |
| Weight & dimensions |
|---|
| Weight | 15.9 oz (450 g) |
| Width | 2.24" (57 mm) |
| Depth | 1.5" (38 mm) |
| Height | 11.5" (292 mm) |
| Operational conditions |
|---|
| Operating temperature (T-T) | 0 - 40 °C |
| Storage temperature (T-T) | -15 - 45 °C |
| Storage relative humidity (H-H) | 0 - 95% |
| Operating relative humidity (H-H) | 0 - 95% |
| Operating altitude | 0 - 118110.2" (0 - 3000 m) |
| Non-operating altitude | 0 - 590551.2" (0 - 15000 m) |
| Certificates |
|---|
| Certification | CSA,NOM,UL 1449 |
| Indication |
|---|
| LED indicators | Yes |
| Packaging data |
|---|
| Package width | 5.79" (147 mm) |
| Package depth | 1.5" (38 mm) |
| Package height | 13.3" (338 mm) |
| Packaging net weight | 1.32 lbs (0.6 kg) |
