| Display |
|---|
| Display diagonal | 85.6" |
| Contrast ratio (typical) | 1200:1 |
| Touchscreen | Yes |
| Panel type | IPS |
| Viewing angle, vertical | 178° |
| Viewing angle, horizontal | 178° |
| Response time | 8 ms |
| Pixel pitch | 0.0194 x 0.0194" (0.493 x 0.493 mm) |
| Vertical scan range | 24 - 75 Hz |
| Horizontal scan range | 30 - 140 kHz |
| Touch technology | Multi-touch |
| Display brightness | 350 cd/m² |
| Display resolution | 3840 x 2160 pixels |
| Display number of colours | 1.073 billion colors |
| HD type | 4K Ultra HD |
| Maximum refresh rate | 60 Hz |
| Native aspect ratio | 16:9 |
| Features |
|---|
| Display diagonal | 85.6" |
| Contrast ratio (typical) | 1200:1 |
| Touchscreen | Yes |
| Panel type | IPS |
| Viewing angle, vertical | 178° |
| Viewing angle, horizontal | 178° |
| Response time | 8 ms |
| Pixel pitch | 0.0194 x 0.0194" (0.493 x 0.493 mm) |
| Vertical scan range | 24 - 75 Hz |
| Horizontal scan range | 30 - 140 kHz |
| Touch technology | Multi-touch |
| Display brightness | 350 cd/m² |
| Display resolution | 3840 x 2160 pixels |
| Display number of colours | 1.073 billion colors |
| HD type | 4K Ultra HD |
| Maximum refresh rate | 60 Hz |
| Native aspect ratio | 16:9 |
| Product colour | Black |
| Audio |
|---|
| Built-in speaker(s) | Yes |
| Built-in microphone | No |
| Network |
|---|
| Ethernet LAN | Yes |
| Ports & interfaces |
|---|
| HDMI ports quantity | 4 |
| Ethernet LAN (RJ-45) ports | 1 |
| RS-232 ports | 1 |
| HDMI version | 2.0 |
| DisplayPorts quantity | 1 |
| DisplayPort version | 1.2 |
| Audio output | 1 |
| Ethernet LAN | Yes |
| Ergonomics |
|---|
| Wall mountable | Yes |
| Product colour | Black |
| Panel mounting interface | 600 x 400 mm |
| Power |
|---|
| Power consumption (typical) | 171 W |
| Power consumption (standby) | 0.3 W |
| Power consumption (off) | 0.3 W |
| AC input frequency | 50 - 60 Hz |
| Power consumption (max) | 430 W |
| Energy efficiency scale | A to G |
| Operational conditions |
|---|
| Operating temperature (T-T) | 0 - 40 °C |
| Operating relative humidity (H-H) | 10 - 80% |
| Storage temperature (T-T) | -20 - 60 °C |
| Storage relative humidity (H-H) | 5 - 90% |
| Technical details |
|---|
| Touchscreen | Yes |
| Panel type | IPS |
| Viewing angle, vertical | 178° |
| Viewing angle, horizontal | 178° |
| Response time | 8 ms |
| Pixel pitch | 0.0194 x 0.0194" (0.493 x 0.493 mm) |
| Vertical scan range | 24 - 75 Hz |
| Horizontal scan range | 30 - 140 kHz |
| Weight & dimensions |
|---|
| Width | 78.1" (1983.7 mm) |
| Depth | 3.3" (83.8 mm) |
| Height | 45.5" (1155.7 mm) |
| Weight | 190.7 lbs (86.5 kg) |
| Packaging data |
|---|
| Package weight | 252.4 lbs (114.5 kg) |
| Projector |
|---|
| Contrast ratio (typical) | 1200:1 |
| Colour |
|---|
| Product colour | Black |
