Scanning |
---|
Maximum scan size | 12.2 x 17.2" (310 x 437 mm) |
Optical scanning resolution | 2400 x 4800 DPI |
Colour scanning | Yes |
Duplex scanning | No |
Input colour depth | 16 bit |
Output colour depth | 48 bit |
Output monochrome depth | 48 bit |
Optical density (Dmax) | 3.8 |
Flatbed scan speed (b/w, A4) | 12 sec/page |
Design |
---|
Built-in display | No |
Product colour | White |
Scanner type | Flatbed scanner |
Performance |
---|
Sensor type | CCD |
Light source | ReadyScan LED |
Scan file formats | JPG, PDF, TIFF |
Scanning noise level | 60 dB |
Paper handling |
---|
Maximum ISO A-series paper size | A3 |
Maximum scan area (ADF) | 12.2 x 17.2" (309.9 x 436.9 mm) |
ISO B-series sizes (B0...B9) | B4, B5 |
ISO A-series sizes (A0...A9) | A3, A4, A5 |
Ports & interfaces |
---|
Standard interfaces | USB 2.0 |
USB connector type | USB Type-B |
USB port | Yes |
USB version | 2.0 |
Power |
---|
Power supply type | AC |
Power consumption (typical) | 55 W |
Input voltage | 100 - 120 V |
System requirements |
---|
Windows operating systems supported | Windows 10, Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 IOT Core, Windows 10 Pro, Windows 10 Pro x64, Windows 7, Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 8, Windows 8 Enterprise, Windows 8 Enterprise x64, Windows 8 Pro, Windows 8 Pro x64, Windows 8 x64, Windows 8.1, Windows 8.1 Enterprise, Windows 8.1 Enterprise x64, Windows 8.1 Pro, Windows 8.1 Pro x64, Windows 8.1 x64, Windows RT 8.1 |
Mac operating systems supported | Mac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion, Mac OS X 10.9 Mavericks |
Operational conditions |
---|
Operating temperature (T-T) | 5 - 35 °C |
Storage temperature (T-T) | 25 - 60 °C |
Operating relative humidity (H-H) | 10 - 80% |
Storage relative humidity (H-H) | 10 - 85% |
Weight & dimensions |
---|
Width | 25.8" (655.3 mm) |
Depth | 18" (457.2 mm) |
Height | 6.2" (157.5 mm) |
Weight | 31.5 lbs (14.3 kg) |
Packaging content |
---|
Drivers included | Yes |
Other features |
---|
Scanner type | Flatbed scanner |
Technical details |
---|
Sustainability certificates | ENERGY STAR |
