Showing 410–420 of 11040 results

The 61-meter (200-foot) N858-61M-3X8-MG MTP/MPO Multimode Base-8 Trunk Cable supports 40/100 Gb Ethernet speeds and is designed for high-density connections between network equipment in telecommunication rooms and data centers.With three female MTP/MPO connectors on each end, this OM4-rated multimode fiber optic cable is recommended for high-density fiber patching between data center MDFs (main distribution frames) and IDFs (intermediate distribution frames). It’s colored magenta for instant identification as an OM4 cable. Push/pull tab connectors are easily accessible in high-density data center applications and make the cable easy to install and remove with one hand.The 8-fiber MTP/MPO connectors are about the same size as SC connectors, but are 12 times denser, freeing up rack space for other cables. Optimized for QSFP+ 40GBASE-SR4 and QSFP28 100GBASE-SR4 networks, this cable is tested for low insertion loss and back reflection on every connector and attenuation loss that meets or exceeds current standards. The 5.6-millimeter ruggedized plenum-rated jacket and bend-insensitive fiber are perfect for connecting high-speed network components in ceilings, walls and ducts.

Multimode duplex fiber optic SC/ST Ethernet cable is manufactured from 62.5/125 zipcord fiber. The cable has ST to SC connectors, a PVC jacket and is FDDI and OFNR rated. Duplex multimode fiber is most commonly used in LAN applications.

Tripp Lite N304-06M. Cable length: 236.2" (6 m), Cable type: OFNR, Connector 1: 2x SC, Connector 2: 2x ST, Core diameter: 62.5 µm

Manufactured from 62.5/125 duplex (zipcord) fiberPVC jacketLength: 8-meters (25ft) Connectors: MTRJ to 2 STInsertion loss testing performed on every connector (0.2db typical) and provided with cableBeveled edge on ends of glass makes insertion of plug a breezeFiber made from glass (not a polymer)Color coded shrouds identify transmit and receiveFiber optic distributed data interface (FDDI) ratedOFNR (riser rated)

Manufactured from 62.5/125 duplex (zipcord) fiberPVC jacketLength: 25-meter (80ft) Connectors: 2 SC/LC connectors on each endInsertion loss testing performed on every connector (0.2db typical) and provided with cableBeveled edge on ends of glass makes insertion of plug a breezeFiber made from glass (not a polymer)

This singlemode duplex fiber optic SC/ST Ethernet cable is manufactured from 9/125 zipcord fiber. The cable has ST connectors on one end, SC on the other, a PVC jacket, and is FDDI and OFNR rated. Duplex singlemode fiber is most commonly used in LAN applications.

This plenum-rated singlemode duplex fiber optic LC/ST Ethernet cable is manufactured from 9/125 zipcord fiber. The cable has LC connectors on one end, ST connectors on the other, and is FDDI and OFNR rated. Duplex singlemode fiber is most commonly used in LAN applications. Plenum cable is used in plenum return air chambers where local fir codes dictate the use of plenum-rated cable.

This 15-meter multimode duplex Fibre Channel SC/SC Ethernet cable is manufactured from 50/125 zipcord fiber. The cable has SC connectors on each end, a PVC jacket and is FDDI and OFNR rated. 50/125 Duplex multimode fiber is most commonly used in Fibre Channel applications. It is backward compatible with 62.5 micron fiber and built-in headroom for future applications. The cable provides higher bandwidth optimized for Gigabit and 10 Gbps networks as well. Also available in 1, 2, 3, 5, 10, 30 and 50 meter lengths. Search "N506-" to bring up all lengths. Also search "N516-" for SC-LC cables, and "N520-" for LC-LC cables.

Constructed with 50/125 micron cableLength - 20MUse on fiber and fibre channel installationsLC male to SC male connectorsHigher bandwidth optimized for gigabit and 10Gbps networksBackward compatible with 62.5 micron fiberBuilt-in headroom for future applicationsNumber of fibers: 2Fiber type: all glass graded indexCore diameter: Two 50+/-3 micronsCLAD diameter: 125+/-2 micronsPrimary coating diameter: 245+/-15 micronsPrimary coating material: acrylateSecondary coating diameter: 900+/-50 micronsSecondary coating material: PVCAttenuation @850NM: 3.5DB/KM maximum, @1300NM: 1.0DB/KM maximumBandwidth @850NM: 220 MHz-KM minimum, @1300NM: 600 MHz-KM minimumBandwidth @850NM: 220 MHz-KM minimum, @1300NM: 600 MHz-KM minimumProof test level: 100,000 PSIInsertion loss testing performed on every connector (0.2db typical) and provided with cableBeveled edge on ends of glass makes insertion of plug a breeze

Constructed with 50/125 micron cable Length - 10M Use on fiber and fibre channel installationsLC male to ST male connectorsHigher bandwidth optimized for gigabit and 10Gbps networksBackward compatible with 62.5 micron fiber Built-in headroom for future applications
